Dough dividing and round-moulding machine
TEWIMAT with TW PLUS

The dough dividing machine with
remoulding module for the highest
demands in industrial round-moulding
of bread roll dough

Accurate dividing and gentle on the dough
The double moulding path preserves the dough structure even in well-risen dough
Optional flouring or oiling between the two moulding procedures

TEWIMAT with TW PLUS

The perfect shape for each dough piece

Preserving the dough structures during processing, perfect results when round-moulding and the option to process particularly soft dough in large quantities make the TEWIMAT the ideal dough dividing and round moulding machine for the industrial production or artisan-like baked goods.

High weight range

In combination of TEWIMAT BIG BALL and the TEWIMAT SOFT, it is possible to process soft, sticky dough up to a weight of 600 g.

Flexible number of lanes

Functional reliability

Exemplary profitability and high quality level

Abbildung der Maschine TEWIMAT in der Produktionsumgebung

Sechs unterschiedliche belegte Pizzastücke in Pizzaform angeordnet

Processing of soft dough

Optimal production solutions for the industrial production of any type of pizza

Reduced production costs thanks to oil-free dividing process

Bestäubung des Teiglings mit Mehl im Teigteiler TEWIMAT

Operating status instantly visible
Dough dividers and molding machines equipped with LEDs

All WP dough dividers and molding machines are now equipped with LEDs indicating their status. The LEDs light up in colors Blue, Yellow, Red, and White. The brightness can be set to suit the ambient conditions. The high-intensity LEDs are clearly visible even in bright light. In conjunction with the new door design, the dough dividers and molding machines make eye-catchers in production.

White: in operation
The LED lights up white. Everything in order.

Blue: cleaning operation
The LED lights up blue. The machine is in cleaning operation. Once cleaning is complete and the machine is operational, the LED lights up yellow.

Red: malfunction
The LED lights up red. Operation is disrupted.

Yellow: Ready for operation
The LED lights up yellow. The machine is operational.

Performance, maximum benefit, and modular options

Thanks to its suction divider technology and variable pressure adjustment, the TEWIMAT ensures gentle dough dividing. The innovative double piston system allows a wide product variety.

Product diversity:
- Processing of wheat dough
- Processing of mixed rye dough
- Processing of Berliner dough
- Processing of fruit dough
- Processing of Graham dough
Quality:
- Suction divider technology and variable pressure adjustment ensure gentle dough dividing
- Product diversity thanks to innovative double piston system
Cleaning:
- Oil-free dividing process
- All dough-handling parts can be removed largely without tools
- All dough-handling parts are consistently separated from the drive mechanism
- Stainless steel paneling
Flexibility:
- flexible number of lanes
- flexible weight setting
- flexible weight range
- flexible capacity adjustment

Weight range:

from 28 g to 600 g
(depending on machine configuration)

Hourly capacity:

max. 2,000 pieces/lane
(depending on dough and weight)

(further technical information to be
found in datasheet and brochure)

Looking for a different product? World of products

Options

TW PLUS
The TW PLUS is an external second moulding station installed downstream. The dough is thus handled particularly gently. The double moulding path preserves the dough structure even in well-risen dough. Optional flouring and oiling between the two moulding procedures increase the flexibility considerably.
TEWIMAT BIG BALL/TEWIMAT SOFT functional module
In combination of TEWIMAT BIG BALL and the TEWIMAT SOFT functional modules, the processing of soft, sticky dough with a yield of up to 170 (depending on the quality of the flour used) is also possible up to a weight of 450 g.
CleanTec spreading belt
Divided cleaning brush
Removable belt driving roller
